◆ Image Pick-up Device : Sharp CCD   ( Sony Optional)
     ◆ Number of Pixels : NTSC : 510(H)x492(V); PAL : 500(H)x582(V)

◆ Horizontal Resolution: 420 TV Lines

◆ IR LEDS : 18 pcs blue

◆ Usable Illumination : 1 Lux(F:1.2), 0 Lux with IR LED

◆Waterproof Resistance : IP 69

◆ IR project distance : 15 meters

◆ Scanning System : NTSC : 525 Lines, 60 Field/sec; PAL: 625 Lines,50 Field/sec

◆ Sync System: Internal Synchronization

◆ Lens :2.8mm standard , 2.1~3.6mm (optional)
    ◆ Angle : 120 degree

◆ Video Output :1.0 Vp-p 75 ohm

◆ Gain Control (AGC): Auto

◆ Operation Temperature : -20℃～ +60℃ RH95% Max

◆ Storage Temperature: -30℃～+70℃ RH95% Max
