Model No.:
Peugeot Expert /Citroen Space Tourer/ Toyota Proace
+86-13580347156
Detailed Product Description:
Specification :
B1.Product Features
1.Use 1/3CMOS sensor,support analog hd video 700TVL
2.Waterproof grade IP69K
3.Support mirror switching and ruler control functions
4.With night vision function, infrared distance 6m
B2.Specifications
Image Sensor
1/3 CMOS PC1058K
TV System
NTSC/PAL
Effective Pixels
976(H)*592(V)
Sensing Area
4.880mm*3.670mm
Sync. System
Internal
Resolution
700 TVL
Minimum Illumination
0.1 Lux (day), 0 Lux (with IR)
Microphone
Optional
IR LED Qty
2 PCS
Video Output
1.0 Vp-p/75 Ohm
Scanning System
interlace
AGC
AUTO
Signal to noise ratio
Better than 48dB
White balance
AUTO
Gamma Consumption
0.45
Electronic Shutter
AUTO
Backlight Compensation
AUTO
Power Supply
DC12V
Lens
1.7mm
Lens Angle
145°
Current Drain
Daytime current 50mA ± 5, night vision current 210mA ± 5
Operating Temperature
-20
℃
-70
℃
,RH 95% MAX
Storage Temperature
-30
℃
-80
℃
,RH 95% MAX
C1.Accessories
1.Extension cable 2.JenaLabs 3.Power cord 4.RCA adapter 5.Manual
