 Specification :
◆ Digital Panel : 800 * 480 * RGB resolution ,16:9 display
◆ System Resource : 4 Channel rear time recording
◆ Video Format : PAL , NTSC
◆ Video Compression : H.264
◆ Audio Compression : ADPCM
◆ Video Input : 4 Channel with 4 pin connector
◆ Video Output : 1 Channel with RCA connector
◆ Audio Input : 4 Channel with 4 pin connector
◆ Audio Output : 1 Channel with 4 pin connector
◆ Display : Single, Quad Pictures
◆ Recording Speed : PAL:25FPS(adjustable) , NTSC:30FPS(adjustable)
◆ Recording By : Manual , Timer ,Alarm (Option)
◆ Searching By : Time, Channel , Event
◆ Back Up : Through USB
◆ Video Save : SD card, U Disc
◆ Playback : 1 channel ,4 channels
◆ Alarm Input : 4 triggers (Optional)
◆ Save Interface : 4 USB and 1 SD
◆ Ignition Signal : 1
◆ Power Supply : DC 8V-32V
◆ Working Temperate : 00C---600C
◆ Storage Temperate : -100C--- 700C
◆ Dimension : 138 * 120 * 40 mm
|
